Key Features
◈
Model: Crawler Excavator-WINGS SH230.
◈
Operating Weight: 23,000kg.
◈
Product Type: Heavy-duty, tracked type.
◈
Engine: Cummins diesel engine.
◈
Durable Steel Tracks: Built with robust steel tracks, the excavator ensures durability and reliable performance on challenging terrains.
◈
Negative Flow Constant Power Variable System: Adjusts hydraulic flow and pressure according to workload, ensuring stable engine power for improved efficiency and reduced fuel consumption.
Applications
■
Energy Engineering Projects: Ideal for wind turbine foundation excavation, oil pipeline trenching, highway deep cutting, and reservoir dam construction in large-scale energy projects.
■
Emergency Rescue Operations: Perfect for disaster relief, including demolishing unsafe structures after earthquakes and clearing flood-affected river channels.
■
Infrastructure and Earthmoving: Suitable for construction tasks like land leveling, trench digging, and foundation preparation across various terrains.
Main Parameter
| Performance |
Bucket Capacity |
m3 |
1.1 |
| Total Weight |
kg |
22500 |
| Swing Speed |
rmp |
11-13 |
| Gradeability |
° |
30 |
| Max. Bucket Digging Force |
KN |
140 |
| Max. Arm Digging Force |
KN |
99 |
| Engine Model |
- |
Cummins 6BTAA5.9-C178 |
| Power/Revolution Speed |
KW/rmp |
133 |
| System Pressure |
MPa |
34 |
| Overall Dimensions |
Dimension (L*W*H) |
mm |
9590x2980x3185 |
| Cabin Height |
mm |
3060 |
| Axle Base |
mm |
3655 |
| Track Distance |
mm |
2380 |
| Ground Clearance |
mm |
470 |
| Tail Swing Radius |
mm |
2880 |
| Working Range |
Max. Digging Height |
mm |
9410 |
| Max. Dumping Height |
mm |
6730 |
| Max. Digging Depth |
mm |
6480 |
| Max. Vertical Digging Depth |
mm |
5925 |
| Max. Digging Radius |
mm |
9850 |
| Min. Swing Radius |
mm |
3555 |
Why Choose SH230?
✔
User-Friendly Operation and Comfort: Ergonomic cabin designs, intuitive controls, and advanced safety features make excavators easy and comfortable to operate, minimizing operator fatigue.
✔
Trusted Performance: Delivers products that meet international standards of quality and performance, trusted by professionals for heavy-duty jobs.
✔
Comprehensive After-Sales Support: Excellent customer service including spare parts availability and technical support throughout the equipment lifecycle.
Engineered for large-scale operations, the SH230 combines robust performance with reliable output. The SH-Series integrates heavy-duty steel tracks and cutting-edge hydraulics to deliver top-tier power and efficiency in extreme conditions. From industrial excavation to energy infrastructure projects, these machines are your go-to equipment for mission-critical applications.
Frequently Asked Questions
1. What is the operating weight of the SH230 crawler excavator?
The operating weight of the SH230 model is approximately 23,000kg (22.5 tons), making it suitable for heavy-duty earthmoving and construction tasks.
2. Which engine powers the SH230 excavator?
This excavator is equipped with a high-performance Cummins 6BTAA5.9-C178 diesel engine, providing 133 KW of power.
3. What is the benefit of the Negative Flow Constant Power Variable System?
This advanced hydraulic system automatically adjusts flow and pressure based on the workload. This ensures stable engine power, improves operational efficiency, and helps reduce fuel consumption.
4. Can this excavator be used for disaster relief?
Yes, it is ideal for emergency rescue operations, including clearing flood-affected river channels and demolishing unsafe structures after earthquakes.
5. What are the maximum digging capabilities of the SH230?
The machine features a maximum digging height of 9,410mm, a maximum digging depth of 6,480mm, and a maximum digging radius of 9,850mm.
6. Is the excavator cabin designed for long working hours?
Yes, the cabin features an ergonomic design with intuitive controls and safety features specifically built to maximize operator comfort and reduce fatigue during extended shifts.
